Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controllers Points Of Technique 10
10-14
Full program listing:
Program options:
0LDX 4 35STLS 1 72STLS21
1 AND X 2 36 LD M 35 73 SET Y 1
2 ANI Y 1 37 RST M 8043 74 OUT T 0
3 OUT M 8044 39 ANI Y 1 K 10
5 LD M 8000 40 SET S 10 77 LD T 0
6 IST 60 42 STL S 10 78 SET S 22
M 30 43 RST Y 1 80 STL S 22
S20 44RSTY 0 81OUTY 2
S 27 45 OUT Y 2 82 LD X 2
13 STL S 0 46 LD X 2 83 SET S 23
14 LD M 8044 47 SET S 11 85 STL S 23
15 OUT M 8043 49 STL S 11 86 OUT Y 3
17 LD M 22 50 RST Y 3 87 LD X 3
18 SET Y 1 51 OUT Y 4 88 SET S 24
19 LD M 17 52 LD X 4 90 STL S 24
20 RST Y 1 53 SET S 12 91 OUT Y 0
21 LD M 15 55 STL S 12 92 LD X 1
22 ANI Y 0 56 SET M 8043 93 SET S 25
23OUTY 2 58RSTS12 95STLS25
24 LD M 20
(RET)*
96 RST Y 1
25 ANI Y 2 60 STL S 2 97 OUT T 1
26 OUT Y 0 61 LD M 8041 K 10
27 LD M 16 62 RST M 8043 100 LD T 1
28 AND X 2 64 AND M 8044 101 SET S 26
29 ANI Y 3 65 SET S 20 103 STL S 26
30 OUT Y 4 67 STL S 20 104 OUT Y 2
31 LD M 21 68 OUT Y 0 105 LD X 2
32 AND X 2 69 LD X 1 106 SET S 27
33 ANI Y 4 70 SET S 21 108 STL S 27
34 OUT Y 3 109 OUT Y 4
(RET)*
110 LD X 4
↑
This instruction returns the
program flow to STL step S2.
→ 111 OUT S 2
*: Instructions in ( ) are not
necessary
113 RET
necessary
114 END
6 IST 60 17 LD X12 27 LD X6
X20 19 LD X7 31 LD X11
S20 21LDX5 36 LD X25
S27 24LDX10

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
