If any high speed comparison instructions (FNC’s 53, 54, 55) are used, X0 and X1 must resort
to software counting. In this case, please see the table below:
Unit
Function
Number
Max. Combined
Signal Frequency
FX
2N &FX2NC
53 or 54 11 kHz
55 5.5 kHz
FX
1S &FX1N 53 or 54 30 kHz
Calculating the maximum combined counting speed on FX1S:
Thisiscalculatedasfollows:(2 phase counter speed x number of counted edges) :
(the sum of the speeds of the active 1 phase counters).

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
