3.1 Generic Specifications
*1.
*2. The PLC cannot be used at a pressure higher than the atmospheric pressure to avoid damage.
Item Specification
Ambient
temperature
0 to 55°C (32 to 131°F) when operating and -25 to 75°C (-13 to 167°F) when stored
Ambient
humidity
5 to 95%RH (no condensation) when operating
Vibration
resistance
Frequency
(Hz)
Acceleration
(m/s
2
)
Half amplitude
(mm)
Sweep Count for X, Y, Z: 10
times
(80 min. in each direction)
When installed
on DIN rail
10 to 57 - 0.035
57 to 150 4.9 -
When installed
directly
10 to 57 - 0.075
57 to 150 9.8 -
Shock
resistance
147m/s
2
Acceleration, Action time: 11ms, 3 times by half-sine pulse in each direction X, Y, and Z
Noise
resistance
By noise simulator at noise voltage of 1,000Vp-p, noise width of 1µs, rise time of 1ns and period of 30
to 100Hz
Dielectric
withstand
voltage
500V AC for one minute
Comply with JEM-1021
Between batch of all terminals and ground terminal
Insulation
resistance
5MΩ or more by 500V DC megger
Grounding
Class D grounding (grounding resistance: 100Ω or less)
<Common grounding with a heavy electrical system is not allowed.>
*1
Working
atmosphere
Free from corrosive or flammable gas and excessive conductive dusts
Working
altitude
< 2000m
*2
PLC
Other
equipment
Shared grounding
Good condition
Common grounding
Not allowed
Independent grounding
Best condition
PLC
Other
equipment
PLC
Other
equipment

Mitsubishi FX3UC Series Specifications

General
