FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.12 Selection Calculation Example 1 for System Configuration
1
Outline
2
External
Dimensions
3
Generic
Specifications
4
Power Supply
Specifications
5
Input
Specifications
6
Output
Specifications
7
Examples of
Wiring for
Various Uses
8
Terminal Block
9
CC-Link/LT
Master FX
3UC
(LT only)
10
Display module
FX
3UC
(LT only)
1.12.1 Re-examination of suitability for configuration
In this configuration, it is necessary to add an extension power supply unit FX3UC-1PS-5V due to the
restrictions in 5V DC power supply capacity and the restriction regarding the number of connectable units.
Construct the system as follows.
1. Components after countermeasures
Connect the extension power supply unit FX3UC-1PS-5V in place of the FX2NC-CNV-IF.
2. Reexamination of system configuration availability
1) Restriction for the number of input/output points
There is no problem since the number of input/output points in the new system is "200".
2) Restriction for the 5V DC power supply capacity
The 5V DC power supply capacity is as follows after the countermeasures.
- Main unit side
- Extension power supply unit side
FX
3UC
-
64MT/D
FX
2NC
-
32EX
FX
2NC
-
16EYR-T
FX
2NC
-
4DA
FX
3UC
-
4AD
FX
2N
-
10PG
FX
3U
-
20SSC-H
FX
2NC
-
16EYR-T
FX
2NC
-
32EX
FX
3U
-
485ADP
(-MB)
FX
3U
-
232ADP
(-MB)
FX
0N
-
3A
FX
3UC
-
1PS-5V
OK!!
a)Supplier side
FX
3UC
-64MT/D 480mA
b)Consumer side
There is no problem since the total current consumption is less than the
capacity "480mA" supplied by the main unit.
"a)Supplier side" - "b)Consumer side" = 480mA - 400mA = 80mA
0mA
5V DC power supply capacity and current consumption
OK!!
FX
2NC
-32EX
FX
2NC
-16EYR-T
60mA
50mA
50mA
110mA
170mA
220mA
FX
2NC
-32EX 60mA
FX
3U
-232ADP(-MB) 30mA
FX
3U
-485ADP(-MB) 20mA
FX
2NC
-16EYR-T
FX
2NC
-4DA
50mA
30mA
100mAFX
3UC
-4AD
270mA
300mA
400mA
a)Supplier side
FX
3UC
-1PS-5V 1A (1000mA)
b)Consumer side
FX
2N
-10PG
FX
3U
-20SSC-H
120mA
100mA
30mA
There is no problem since the total current consumption is less than the
capacity "1A (1000mA)" supplied by the Extension power supply unit.
FX
0N
-3A
220mA
"a)Supplier side" - "b)Consumer side" = 1000mA - 250mA = 750mA
0mA
5V DC power supply capacity and current consumption
OK!!
250mA
