FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
C Operation of Special Devices (M8000 -, D8000 -)
C-3 Analog special adapters special devices
Appendix C-3-2 Special data registers (D8260 to D8299)
Number
Operation and function
FX3U-4AD-ADP FX3U-4DA-ADP FX3U-4AD-PT-ADP FX3U-4AD-TC-ADP
Compatible
Versions
Ver. 1.20 or later Ver. 1.20 or later Ver. 1.30 or later Ver. 1.30 or later
1st analog special adapter
D 8260 Input data Ch1 Output data Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8261 Input data Ch2 Output data Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8262 Input data Ch3 Output data Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8263 Input data Ch4 Output data Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8264
Number of averaging times for
Ch1 (1 to 4095)
Not used
Number of averaging times for
Ch1 (1 to 4095)
Number of averaging times for
Ch1 (1 to 4095)
D 8265
Number of averaging times for
Ch2 (1 to 4095)
Not used
Number of averaging times for
Ch2 (1 to 4095)
Number of averaging times for
Ch2 (1 to 4095)
D 8266
Number of averaging times for
Ch3 (1 to 4095)
Not used
Number of averaging times for
Ch3 (1 to 4095)
Number of averaging times for
Ch3 (1 to 4095)
D 8267
Number of averaging times for
Ch4 (1 to 4095)
Not used
Number of averaging times for
Ch4 (1 to 4095)
Number of averaging times for
Ch4 (1 to 4095)
D 8268 Error status Error status Error status Error status
D 8269 Model code: K1 Model code: K2 Model code: K20 Model code: K10
2nd analog special adapter
D 8270 Input data Ch1 Output data Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8271 Input data Ch2 Output data Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8272 Input data Ch3 Output data Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8273 Input data Ch4 Output data Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8274
Number of averaging times for
Ch1 (1 to 4095)
Not used
Number of averaging times for
Ch1 (1 to 4095)
Number of averaging times for
Ch1 (1 to 4095)
D 8275
Number of averaging times for
Ch2 (1 to 4095)
Not used
Number of averaging times for
Ch2 (1 to 4095)
Number of averaging times for
Ch2 (1 to 4095)
D 8276
Number of averaging times for
Ch3 (1 to 4095)
Not used
Number of averaging times for
Ch3 (1 to 4095)
Number of averaging times for
Ch3 (1 to 4095)
D 8277
Number of averaging times for
Ch4 (1 to 4095)
Not used
Number of averaging times for
Ch4 (1 to 4095)
Number of averaging times for
Ch4 (1 to 4095)
D 8278 Error status Error status Error status Error status
D 8279
Model code: K1 Model code: K2 Model code: K20 Model code: K10
3rd analog special adapter
D 8280 Input data Ch1 Output data Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8281 Input data Ch2 Output data Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8282 Input data Ch3 Output data Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8283 Input data Ch4 Output data Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8284
Number of averaging times for
Ch1 (1 to 4095)
Not used
Number of averaging times for
Ch1 (1 to 4095)
Number of averaging times for
Ch1 (1 to 4095)
D 8285
Number of averaging times for
Ch2 (1 to 4095)
Not used
Number of averaging times for
Ch2 (1 to 4095)
Number of averaging times for
Ch2 (1 to 4095)
D 8286
Number of averaging times for
Ch3 (1 to 4095)
Not used
Number of averaging times for
Ch3 (1 to 4095)
Number of averaging times for
Ch3 (1 to 4095)
D 8287
Number of averaging times for
Ch4 (1 to 4095)
Not used
Number of averaging times for
Ch4 (1 to 4095)
Number of averaging times for
Ch4 (1 to 4095)
D 8288 Error status Error status Error status Error status
D 8289 Model code: K1 Model code: K2 Model code: K20 Model code: K10
4th analog special adapter
D 8290 Input data Ch1 Output data Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8291 Input data Ch2 Output data Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8292 Input data Ch3 Output data Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8293 Input data Ch4 Output data Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8294
Number of averaging times for
Ch1 (1 to 4095)
Not used
Number of averaging times for
Ch1 (1 to 4095)
Number of averaging times for
Ch1 (1 to 4095)
D 8295
Number of averaging times for
Ch2 (1 to 4095)
Not used
Number of averaging times for
Ch2 (1 to 4095)
Number of averaging times for
Ch2 (1 to 4095)
D 8296
Number of averaging times for
Ch3 (1 to 4095)
Not used
Number of averaging times for
Ch3 (1 to 4095)
Number of averaging times for
Ch3 (1 to 4095)
D 8297
Number of averaging times for
Ch4 (1 to 4095)
Not used
Number of averaging times for
Ch4 (1 to 4095)
Number of averaging times for
Ch4 (1 to 4095)
D 8298 Error status Error status Error status Error status
D 8299 Model code: K1 Model code: K2 Model code: K20 Model code: K10
