Mitsubishi FX3UC Series User Manual

333
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
10 Display Module (Only FX3UC-32MT-LT)
10.7 Error Check
1
Outline
2
External Dimensions
3
Generic Specifications
4
Power Supply Specifications
5
Input Specifications
6
Output Specifications
7
Examples of Wiring for Various Uses
8
Terminal Block
9
CC-Link/LT Master FX
3UC
(LT only)
10
Display module FX
3UC
(LT only)
10.6.2 Test mode operation
1) Perform a monitor mode operation to display the user-registered
device whose current value is to be changed.
→ Refer to Subsection 10.5.2 for monitor function operation.
2) Hold the [OK] button for 1 second or longer to switch to the test
mode. The current value then begins blinking (refer to fig. at right).
3) Use the [+]/[-] buttons to change the value as desired. To cancel the
operation and return to the "monitor screen", press [ESC].
4) Press [OK] to register the current value and return to the "user registered devices screen".
10.7 Error Check
The main unit’s error status displays at the "ErrorCheck" menu.
1) At the menu screen, use the [+]/[-] buttons to move the cursor to the
"ErrorCheck" item, then press [OK].
The error check result then displays at the "error display screen"
(refer to fig. at right).
To cancel the operation and return to the "Main unit I/O operation
display", press [ESC] at the menu screen
2) If multiple errors have occurred, the [+]/[-] keys can be used to
switch between the error display pages.
Display Content
3) To cancel the operation and return to the "menu screen", press
[ESC].
Button Operation Description
ESC
Cancels the operation and returns to the "monitor
screen".
-
Reduces the value.
Hold for 1 second or longer for high-speed reduction.
+
Increases the value.
Hold for 1 second or longer for high-speed increase.
OK
Registers the current value and returns to the "monitor
screen".
Button Operation Description
ESC Returns to the "menu screen".
-
1 error or less Disabled
2 errors or more Displays the previous-page’s error screen.
+
1 error or less Disabled
2 errors or more Displays the next-page’s error screen.
OK Returns to the "menu screen".
Display Content
[1]
Active error flag
[2]
Error name
[3]
Error code
[4]
Number of concurrent errors
(displays only when multiple errors have occurred)
D 100
10
Ha l t t ime r
D 100
10
Ha l t t ime r
D 100
20
Ha l t t ime r
When no errors have occurred
When one error has occurred
[1]
[2]
[3]
When more than one error has
occurred
[1]
[2]
[3]
/12
[1]
[2]
[3]
[4]
[4]
+-
Er rorCheck
No E r r o r
Er rorCheck
Er rorCheck
/22Er rorCheck
M8063
errorLink 1
Er r or code 6301
M8060
er rI/O
Er r or code 1020
M8066
errorLadde
Er r or code 6612
r
