10 Display Module (Only FX3UC-32MT-LT)
10.13 PLC Status
10.13 PLC Status
The PLC statuses shown below can be displayed from the "PLC Status" menu.
→ Refer to Subsection 10.13.2 for display details.
10.13.1 Display operation
1) At the menu screen, use the [+]/[-] buttons to move the cursor to the
"PLC Status" item, then press [OK] to display the "PLC Status (1/3)"
screen.
To cancel the operation and return to the "Main unit I/O operation
display", press [ESC].
2) Use the [+]/[-] buttons to switch between the PLC Status screen
pages.
Press [OK] or [ESC] to return to the "menu screen".
3) Press [OK] or [ESC] to return to the "menu screen".
Page Title Display Item
PLC Status (1/3)
• Version
• Entry code status
PLC Status (2/3)
• Program memory type
• Memory cassette’s write protect status
• Program memory capacity
PLC Status (3/3)
• Battery voltage
• Number of registered comments
Button Operation Description
ESC Returns to the "menu screen".
-
Returns to the previous page.
+
Proceeds to the next page.
OK Returns to the "menu screen".
PL
reV1.00
auts
.
CtS(/13)
PL
reV1.00
auts
.
CLPop
CtS
eartion
lsiimtie
(/13)
d
llA ope artion
usinrsetri tced
64K
--
00/ 002001
PL a utsCtS(/23)
taBte .2V3
tnes
PL a utsCtS(/33)
ry
moCm
meMory
orPtecti
paC
on
tnIernla
ac i t y
PLC Status (3/3) PLC Status (2/3) PLC Status (1/3)
PLC Status (1/3) PLC Status (2/3) PLC Status (3/3)
