FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.12 Selection Calculation Example 1 for System Configuration
1
Outline
2
External Dimensions
3
Generic Specifications
4
Power Supply Specifications
5
Input Specifications
6
Output Specifications
7
Examples of Wiring for Various Uses
8
Terminal Block
9
CC-Link/LT Master FX
3UC
(LT only)
10
Display module FX
3UC
(LT only)
1.12 Selection Calculation Example 1 for System Configuration
When the main unit is the FX3UC-64MT/D.
1. System equipment
2. Confirmation of system configuration availability
1) Restriction in number of input/output points
The I/O points restriction is satisfied since the total number of input/output points is less
than 256.
Number of input / occupied output points
a) Main unit (Number of input / occupied output points)
Total of a)
64 points
FX
3UC-64MT/D 64 points
b) I/O extension block
(Number of input / occupied output points)
Total of b)
32 + 32 + 16 + 16 = 96
96 points
FX
2NC-32EX 32 points
FX
2NC-32EX 32 points
FX
2NC-16EYR-T 16 points
FX
2NC-16EYR-T 16 points
c) Special adapter
(Number of input / occupied output points)
Total of c)
0 + 0 = 0
0 points
FX
3U-232ADP(-MB) 0 points
FX
3U-485ADP(-MB) 0 points
d) Special function units / blocks
(Number of input / occupied output points)
Total of d)
8 + 8 + 8 + 8 + 8 = 40
40 points
FX
2NC-4DA 8 points
FX
3UC-4AD 8 points
FX
2N-10PG 8 points
FX
3U-20SSC-H 8 points
FX
0N-3A 8 points
Total number of I/O points
a) + b) +c) +d) =
64 + 96 + 0 + 40 = 200<256 points
FX 3UC -
64MT/D
FX 2NC -
32EX
FX 2NC -
16EYR-T
FX 2NC -
4DA
FX 3UC -
4AD
FX 2NC -
CNV-IF
FX 2N -
10PG
FX 3U -
20SSC-H
FX 2NC -
16EYR-T
FX 2NC -
32EX
FX 3U -
485ADP
(-MB)
FX 3U -
232ADP
(-MB)
FX 0N -
3A
OK!!
