Mitsubishi FX3UC Series User Manual

60
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.11 Number of occupied I/O points and 5V DC current consumption
6. Extension power supply unit/Connector conversion adapter
7. GOT/programming tool
*1. When the FX-20P-RWM is used, the current is 180mA.
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX
3UC-1PS-5V 0 -
FX
2NC-CNV-IF 0 -
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX-20P(-SET0) -
150
*1
FX-20P-E(-SET0) -
150
*1
FX-10P(-SET0) - 120
FX-10P-E(-SET0) - 120
FX-232AW - 220
FX-232AWC - 220
FX-232AWC-H - 120
FX-USB-AW - 15
FX-10DM(-SET0) - 220
F920GOT-BBD5-K - 220
E
E1
E2
F
F1
