FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.11 Number of occupied I/O points and 5V DC current consumption
1
Outline
2
External
Dimensions
3
Generic
Specifications
4
Power Supply
Specifications
5
Input
Specifications
6
Output
Specifications
7
Examples of
Wiring for
Various Uses
8
Terminal Block
9
CC-Link/LT
Master FX
3UC
(LT only)
10
Display module
FX
3UC
(LT only)
5. Special function devices
- Special function blocks
*1. For the number of input/output occupied points in the FX
2N-16CCL-M, FX2N-64CL-M and FX2N-
32ASI-M, refer to the table below.
*2. Varies depending on the configuration of products connected to the network.
For details, refer to the FX
2N-16LNK-M manual.
- Special function units
Division Model name
Number of input/
output points
5V DC current
consumption mA)
FX
3UC-4AD 8 100
FX
2NC-4AD 8 50
FX
2NC-4DA 8 30
FX
2N-2AD 8 20
FX
2N-2DA 8 30
FX
2N-4AD 8 30
FX
2N-4DA 8 30
FX
2N-4AD-TC 8 30
FX
2N-4AD-PT 8 30
FX
2N-8AD 8 50
FX
2N-5A 8 70
FX
2N-2LC 8 70
FX
2N-1HC 8 90
FX
2N-1PG 8 55
FX
2N-1PG-E 8 55
FX
2N-10PG 8 120
FX
2N-232IF 8 40
FX
2N-16CCL-M *1 0
FX
2N-32CCL 8 130
FX
2N-64CL-M *1 190
FX
2N-32ASI-M *1 150
FX
2N-16LNK-M *2 200
FX
3U-4AD 8 110
FX
3U-4DA 8 120
FX
3U-20SSC-H 8 100
FX
0N-3A 8 30
Model name
Number of input/output occupied points
(Use the following formula.)
FX
2N-16CCL-M
Remote I/O stations
× 32 points + 8 points
FX
2N-64CL-M
Total number of input/output points in remote I/O
stations + 8 points
FX
2N-32ASI-M
For main units Ver.2.20 or later
Number of active slaves
× 8 points + 8 points
For main units Ver.2.20 or less
Number of active slaves
× 4 points + 8 points
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX
2N-10GM 8 0
FX
2N-20GM 8 0
FX
2N-1RM-SET 8 0
FX
2N-1RM-E-SET 8 0
D
D1
D2
D3
D4
D3
