338
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
10 Display Module (Only FX3UC-32MT-LT)
10.10 Clock Menu (Current Time Setting)
10.10.2 Displaying the current time
1) At the menu screen, use the [+]/[-] buttons to move the cursor to the
"ClockMenu" item, then press [OK] to display the selection screen
shown to the right.
To cancel the operation and return to the "Main unit I/O operation
display", press [ESC].
2) Use the [+]/[-] buttons to move the cursor to the "Current time" item.
To cancel the operation and return to the "menu screen", press
[ESC].
3) Press the [OK] button to display the current time.
To cancel the operation and return to the "selection screen", press
[ESC].
4) Press [OK] or [ESC] to return to the "selection screen".
5) Press [ESC] to return to the "menu screen".
10.10.3 Changing the current time’s "Year" from 2-digit format to 4-digit format
The "Year" data displays as 2-digit value with a default. This can be changed to a 4-digit display by the
following programming.
It is also possible to set the current time with a sequence program.
→ Refer to the "time setting" (special devices D8013 to D8019) section of the Programming Manual.
Button Operation Description
ESC Returns to the "selection screen".
- Disabled
+ Disabled
OK Returns to the "selection screen".
Crruentt emi
tCcolkset gni
2-digit display
31 . 1 . 04
23 : 59 : 59 [ t ]Sa
4-digit display
31 . 1 . 20
23 : 59 : 59 [ t ]Sa
04
M8002
MOV K2000 D8018
To Next Page
