1.13 Selection Calculation Example 2 for System Configuration
When the main unit is the FX3UC-32MT-LT.
For the calculation of power supply restrictions in the CC-Link/LT system, refer to Subsection 9.6.3.
1. System equipment
2. Confirmation of system configuration availability
1) Restriction for the number of input/output points
Terminating resistor
CL1X4-D1B2
4 points, input units
(Station No.1, Number
of occupied stations 1)
CL1Y4-T1B2
4 points, output units
(Station No.2, Number
of occupied stations 1)
Terminating resistor
FX 3UC -
32MT-
LT
FX 2NC -
32EX
FX 2NC -
16EYR-T
FX 2NC -
16EYR-T
FX 2NC -
4AD
FX 2NC -
CNV-IF
FX 2N -
10PG
FX 2N -
2LC
FX 2NC -
32EYT
FX 2N -
16EYT
FX 2NC -
32EX
a)Main unit (Number of input / occupied output points)
FX 3UC -32MT-LT 32 Points
Number of input/output points occupied
Total of a)
Total of b)
32 + 32 + 32 + 16 + 16 + 16
=144 points
b)I/O extension block
(Number of input / occupied output points)
FX 2NC -32EX
FX 2NC -16EYR-T
FX 2NC -16EYR-T
FX 2NC -32EYT
32 Points
16 Points
16 Points
32 Points
FX 2N -16EYT 16 Points
FX 2NC -32EX 32 Points
d)Special function units / blocks
(Number of input / occupied output points)
c)Total number of input/output points in remote I/O stations for
built-in CC-Link/LT
CL1X4-D1B2
CL1Y4-T1B2
FX 2NC -4AD
FX 2N -10PG
FX 2N -2LC
4 Points
4 Points
8 Points
8 Points
8 Points
Total of c)
4 + 4 = 8 points
Total of d)
8 + 8 + 8 = 24 points
Total number of I/O points
32 + 144 + 8 + 24
= 208 points < 256 points
The restriction for the number of input/output points is satisfied since the total number
of input/output points is less than 256.
OK!!
8 points
144 points
32 points
24 points
