FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.11 Number of occupied I/O points and 5V DC current consumption
4. I/O extension devices
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX
2NC-16EX 16 30
FX
2NC-16EX-DS 16 30
FX
2NC-16EX-T 16 30
FX
2NC-16EX-T-DS 16 30
FX
2NC-16EYT 16 50
FX
2NC-16EYT-DSS 16 50
FX
2NC-16EYR-T 16 50
FX
2NC-16EYR-T-DS 16 50
FX
2NC-32EX 32 60
FX
2NC-32EX-DS 32 60
FX
2NC-32EYT 32 100
FX
2NC-32EYT-DSS 32 100
FX
2N-8ER 16 25
FX
2N-8ER-ES/UL 16 25
FX
2N-8EX-UA1/UL 8 25
FX
2N-8EX 8 25
FX
2N-8EX-ES/UL 8 25
FX
2N-8EYR 8 30
FX
2N-8EYR-ES/UL 8 30
FX
2N-8EYT 8 30
FX
2N-8EYT-ESS/UL 8 30
FX
2N-8EYT-H 8 30
FX
2N-16EX 16 45
FX
2N-16EX-ES/UL 16 45
FX
2N-16EX-C 16 40
FX
2N-16EXL-C 16 35
FX
2N-16EYR 16 40
FX
2N-16EYR-ES/UL 16 40
FX
2N-16EYS 16 160
FX
2N-16EYT 16 180
FX
2N-16EYT-ESS/UL 16 180
FX
2N-16EYT-C 16 180
FX
0N-8ER 16 25
FX
0N-8EX-UA1/UL 8 25
FX
0N-8EX 8 25
FX
0N-8EYR 8 30
FX
0N-8EYT 8 30
FX
0N-8EYT-H 8 30
FX
0N-16EX 16 40
FX
0N-16EYR 16 40
FX
0N-16EYT 16 40
C
C1
C2
C3
