FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
9 CC-Link/LT Built-in master ability (Only FX3UC-32MT-LT)
9.8 Connection of Cables, Connectors and Terminating Resistors
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
2. Attachment procedure
The procedure is shown below.
1) Terminal processing procedure
2) T-branch processing procedure
flat cable in the cover.
Properly place the dedicated1)
This setting position is
wrong.
Note1) If the orange part is seen
through the guide hole in
the front cover, the wiring
is not correct. Open the
cover and perform the
previous step again.
Note2)
(Check that the position of
the orange part is correct.)
flat cable will be held between
Close the cover so that the 2)
both sides of the cover
Orange
Orange
Orange
Orange
Orange
Orange
body and press-fit them with
Assemble the cover with the3)
pliers.
are engaged.
Check that all four latches4)
Press-fitting is completed.
the cover with nippers and
Cut 2 portions of the edge of5)
remove the edge.
steps 3 and 4 shown above
to execute press-fitting.
Follows the instructions of7)
Cut
Orange
Orange
where the T-branch is to be
set.
Set the cover to the point6)
