FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
Generic Names and Abbreviations Used in Manuals
FX Series terminal blocks
Generic name for the following models
FX-16E-TB, FX-32E-TB, FX-16EX-A1-TB, FX-16EYR-TB, FX-16EYT-TB,
FX-16EYT-H-TB, FX-16EYS-TB, FX-16E-TB/UL, FX-32E-TB/UL,
FX-16EYR-ES-TB/UL, FX-16EYT-ES-TB/UL, FX-16EYT-ESS-TB/UL,
FX-16EYS-ES-TB/UL
Extension cables
Generic name for the following models
FX
0N-30EC, FX0N-65EC
Input/output cables
Generic name for the following models
FX-16E-500CAB-S, FX-16E-CAB, FX-16E-CAB-R, FX-A32E-CAB
150, 300 or 500 is entered in .
Connectors for input/output
Generic name for the following models
FX
2C-I/O-CON, FX2C-I/O-CON-S, FX2C-I/O-CON-SA
Power cable
Generic name for the following models
FX
2NC-100MPCB, FX2NC-100BPCB, FX2NC-10BPCB1
Built-in type CC-Link/LT
master
Abbreviation of FX
3UC-32MT-LT built-in master
(Additional) CC-Link/LT
master
Abbreviation of FX
2N-64CL-M master block
CC-Link master Abbreviation of FX
2N-16CCL-M master block
Remote I/O stations
Remote stations that handle information in bit units only
(CL1XY2-DT1D5S, CL1X4-D1B2 etc.)
Remote device stations Remote stations that handle information in bit units and word units
Remote stations Generic name for remote I/O stations and remote device stations
RD station Generic name for remote device stations
Power supply adapter Unit to be connected to supply power to the CC-Link/LT system
Dedicated power supply Power supply to be connected to supply power to the CC-Link/LT system
AS-i master Abbreviation of model FX
2N-32ASI-M AS-i system master block
Peripheral devices
Generic name for programming software, handy programming panel (HPP) and
indicator
Programming software
Abbreviation of model FX-PCS/WIN and FX-PCS/WIN-E programming software
packages
GX Developer
Abbreviation of programming software packages SWD5C-GPPW-J and SWD5C-
GPPW-E
FX-PCS/WIN(-E)
Abbreviation of model FX-PCS/WIN and FX-PCS/WIN-E programming software
packages
Handy programming panels
Generic name for the following models
FX-20P(-SET0), FX-20P-E(-SET0), FX-10P(-SET0), FX-10P-E(-SET0)
RS-232C/RS-422 converters
Generic name for the following models
FX-232AW, FX-232AWC, FX-232AWC-H
RS-232C/RS-485 converters Abbreviation of FX-485PC-IF
Indicators
GOT1000 Series Generic name for GT15, GT11 and GT10
GOT-F900 Series
Generic name for F940WGOT, F940GOT, F930GOT, F920GOT, F940 Handy GOT,
F920 Handy GOT, ET-940
F940WGOT Abbreviation of F940WGOT-TWD
F940GOT Generic name for F940GOT-SWD, F940GOT-LWD, F943GOT-SWD, F943GOT-LWD
F930GOT Generic name for F930GOT-BWD, F933GOT-BWD, F930GOT-BBD-K
F920GOT Generic name for F920GOT-BBD-K, F920GOT-BBD5-K
F940 Handy GOT
Generic name for F940GOT-SBD-H, F940GOT-LBD-H, F943GOT-SBD-H,
F943GOT-LBD-H, F940GOT-SBD-RH, F940GOT-LBD-RH, F943GOT-SBD-RH,
F943GOT-LBD-RH
F920 Handy GOT Abbreviation of F920GOT-BBD-RH
ET-940 Generic name for ET-940BH, ET-940BH-L, ET-940PH, ET-940PH-L
Generic Name and
Abbreviation
Description
