FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
443
D Instruction List
D-3 Applied Instructions ... in Ascending Order of FNC Number
11
Memory
Cassette/Battery
12
Test Run,
Maintenance,
Troubleshooting
A
Version
Information
B
Performance
Specifications
C
Special Devices
(M8000 -,D8000 -)
D
Instruction List
E
Character-code
F
Discontinued
models
External FX Device
80 RS
Serial Communication
81 PRUN
Parallel Run (Octal Mode)
82 ASCI
Hexadecimal to ASCII Conversion
83 HEX ASCII to Hexadecimal Conversion
84 CCD
Check Code
85 VRRD
Volume Read
86 VRSC
Volume Scale
87 RS2 Serial Communication 2
88 PID
PID Control Loop
89 to 99 –
Data Transfer 2
100, 101 –
102 ZPUSH
Batch Store of Index Register
*1
103 ZPOP
Batch POP of Index Register
*1
104 to
109
–
Floating Point
110 ECMP Floating Point Compare
111 EZCP
Floating Point Zone Compare
112 EMOV
Floating Point Move
113 to
115
–
116 ESTR
Floating Point to Character String
Conversion
117 EVAL
Character String to Floating Point
Conversion
118 EBCD
Floating Point to Scientific Notation
Conversion
119 EBIN
Scientific Notation to Floating Point
Conversion
120 EADD Floating Point Addition
121 ESUB
Floating Point Subtraction
122 EMUL
Floating Point Multiplication
123 EDIV
Floating Point Division
124 EXP Floating Point Exponent
125 LOGE
Floating Point Natural Logarithm
126 LOG10
Floating Point Common Logarithm
127 ESQR
Floating Point Square Root
128 ENEG Floating Point Negation
129 INT
Floating Point to Integer Conversion
130 SIN
Floating Point Sine
131 COS
Floating Point Cosine
132 TAN Floating Point Tangent
133 ASIN
Floating Point Arc Sine
134 ACOS
Floating Point Arc Cosine
135 ATAN Floating Point Arc Tangent
FNC No. Mnemonic Function
Floating Point
136 RAD
Floating Point Degree to Radian
Conversion
137 DEG
Floating Point Radian to Degree
Conversion
138, 139 –
Data Operation 2
140 WSUM
Sum of Word Data
*1
141 WTOB
WORD to BYTE
*1
142 BTOW
BYTE to WORD
*1
143 UNI
4-bit Linking of Word Data
*1
144 DIS
4-bit Grouping of Word Data
*1
145, 146 –
147 SWAP
Byte Swap
148 –
149 SORT2
Sort Tabulated Data 2
*1
Positioning Control
150 DSZR
DOG Search Zero Return
151 DVIT
Interrupt Positioning
152 TBL
Batch Data Positioning Mode
*1
153, 154 –
155 ABS
Absolute Current Value Read
156 ZRN Zero Return
157 PLSV
Variable Speed Pulse Output
158 DRVI
Drive to Increment
159 DRVA
Drive to Absolute
Real Time Clock Control
160 TCMP RTC Data Compare
161 TZCP
RTC Data Zone Compare
162 TADD
RTC Data Addition
163 TSUB
RTC Data Subtraction
164 HTOS Hour to Second Conversion
165 STOH
Second to Hour Conversion
166 TRD
Read RTC data
167 TWR Set RTC data
168 –
169 HOUR
Hour Meter
External Device
170 GRY
Decimal to Gray Code Conversion
171 GBIN Gray Code to Decimal Conversion
172 to
175
–
176 RD3A
Read form Dedicated Analog Block
177 WR3A
Write to Dedicated Analog Block
178, 179 –
Extension Function
180 –
*1. Supported in Ver. 2.20 or later
FNC No. Mnemonic Function
To Next Page
