36
(2)
Error history (Un\G1800 to Un\G4999)
Address
(decimal)
Address
(hexadecimal)
Name
Default
*1
Read/Write
*2
1800
708
H
Latest address of error history
0
R
1801
709
H
System area
⎯⎯
to
to
1809
71
1
H
1810
712
H
No.1
Error code
0
R
181
1
713
H
Error time
First two
digits of the
year
Last two
digits of the
year
0R
1812
714
H
Month
Day
0
R
1813
715
H
Hour
Minute
0
R
1814
716
H
Second
Day of the
week
0R
1815
717
H
System area
⎯⎯
to
to
1819
71B
H
1820
71C
H
No.2
Same as No. 1
to
to
1829
725
H
1830
726
H
No.3
Same as No. 1
to
to
1839
72F
H
1840
730
H
No.4
Same as No. 1
to
to
1849
739
H
1850
73A
H
No.5
Same as No. 1
to
to
1859
743
H
1860
744
H
No.6
Same as No. 1
to
to
1869
74D
H
1870
74E
H
No.7
Same as No. 1
to
to
1879
757
H
1880
758
H
No.8
Same as No. 1
to
to
1889
761
H
1890
762
H
No.9
Same as No. 1
to
to
1899
76B
H
37
