159
CHAPTER 11 TROUBLESHOOTING
11
11.4 Error Code List
11.4 Error Code List
If the following errors occur on the A/D converter module while data is written to or read from the CPU module, the
corresponding error code below is stored in Latest error code (Un\G19).
The error is reported to the CPU module also.
Error code
(decimal)
Description and cause of error Action
10
The input range is set with a value outside the setting range for
Switch 1 of the intelligent function module switch setting.
The channel with the invalid setting fits in .
Set a valid value on the intelligent function module
switch setting in the parameter setting.
111 A hardware failure has occurred on the module.
Power off and on the module.
If the error occurs again, a failure might have
occurred on the module. Please consult a local
Mitsubishi representative.
112
A value other than 0 is set to Switch 5 on the intelligent function
module switch setting.
Set 0 to Switch 5 on the intelligent function module
switch setting in the parameter setting.
113
*1
The data in the flash memory has a problem.
Check the digital output value.
If there is a problem of the digital output value,
please consult a local Mitsubishi representative.
120
*1
An invalid value is set to the offset/gain setting.
The channel where the error has occurred cannot be identified.
Start over the offset/gain setting of all channels
where the user range setting is used.
If the error occurs again, a failure might have
occurred on the module. Please consult a local
Mitsubishi representative.
12
*1
An invalid value is set to the offset/gain setting.
The channel where the error has occurred fits in .
Start over the offset/gain setting of the channel
where the error has occurred.
If the error occurs again, a failure might have
occurred on the module. Please consult a local
Mitsubishi representative.
161
*1*2
The G(P).OGSTOR instruction was executed in the offset/gain
setting mode.
Do not execute the G(P).OGSTOR instruction in the
offset/gain setting mode.
162
*1
• The G(P).OGSTOR instruction has been consecutively executed.
• For the offset/gain setting, a setting value has been consecutively
written to the flash memory more than 25 times.
• Execute the G(P).OGSTOR instruction only once
per module.
• Write the setting value into the flash memory only
once for each offset/gain setting.
163
*1
• The G(P).OGSTOR instruction has been executed on a module
different from the one on which the G(P).OGLOAD instruction was
executed.
• The G(P).OGSTOR instruction has been executed ahead of the
G(P).OGLOAD instruction.
• Execute the G(P).OGLOAD and G(P).OGSTOR
instructions to the same module.
• After executing the G(P).OGLOAD instruction on
the module from where data is restored, execute
the G(P).OGSTOR instruction on the module to
where the data is restored.
170
*1
The offset/gain setting was configured exceeding the maximum
number of times.
No more offset/gain setting is reflected on the
operation successfully.
To Next Page
