160
20
*1
• Although the conversion speed has been set to 20µs, the
averaging time value set in CH Time Average/Count Average/
Moving Average (Un\G1 to Un\G4) is outside the range of 2 to
1500ms.
• Although the conversion speed has been set to 80µs or 1ms, the
averaging time value set in CH Time Average/Count Average/
Moving Average (Un\G1 to Un\G4) is outside the range of 2 to
5000ms.
• The averaging time value set in CH Time Average/Count
Average/Moving Average (Un\G1 to Un\G4) is less than "4 ×
Number of used channels × Conversion speed" (ms).
The channel where the error has occurred fits in .
• When the conversion speed is 20µs, set the
averaging time to a value in the range of 2 to
1500ms.
• When the conversion speed is 80µs or 1ms, set
the averaging time to a value in the range of 2 to
5000ms.
• Set the averaging time to a value equal to or more
than "4 × Number of used channels × Conversion
speed" (ms).
30
*1
The averaging count value set in CH Time Average/Count
Average/Moving Average (Un\G1 to Un\G4) is outside the range of 4
to 62500.
The channel where the error has occurred fits in .
Set the averaging count to a value in the range of 4
to 62500.
31
*1
The moving average count value set in CH Time Average/Count
Average/Moving Average (Un\G1 to Un\G4) is outside the range of 2
to 1000.
The channel where the error has occurred fits in .
Set the moving average count to a value in the
range of 2 to 1000.
360
*1
The value set in Conversion speed setting (Un\G26) is outside the
range of 0 to 2.
Set one of the following values in Conversion speed
setting (Un\G26).
• 20µs (0)
• 80µs (1)
•1ms (2)
37
*1
The value set in CH Difference conversion trigger (Un\G172 to
Un\G175) is other than 0 and 1.
The channel where the error has occurred fits in .
Set the value in CH Difference conversion trigger
(Un\G172 to Un\G175) to No request (0) or Trigger
request (1).
40
*1
When the user range is set or restored, values are as follows: Offset
value ≥ Gain value
The channel where the error has occurred fits in .
Set values so that they meet the following condition:
Offset value < Gain value
500
*1
When the offset/gain setting is configured, channels or 0s are set
simultaneously in both Offset/gain setting mode Offset specification
(Un\G22) and Offset/gain setting mode Gain specification (Un\G23).
Correct the setting in Offset/gain setting mode Offset
specification (Un\G22) and/or the Offset/gain setting
mode Gain specification (Un\G23).
6
*1
The settings in CH1 Process alarm lower lower limit value (Un\G86)
to CH4 Process alarm upper upper limit value (Un\G101) are invalid.
The channel with the invalid setting fits in .
A value fits in indicates that the alarm status is as follows:
2: Process alarm lower lower limit value > Process alarm lower
upper limit value
3: Process alarm lower upper limit value > Process alarm upper
lower limit value
4: Process alarm upper lower limit value > Process alarm upper
upper limit value
Correct the settings in CH1 Process alarm lower
lower limit value (Un\G86) to CH4 Process alarm
upper upper limit value (Un\G101).
80
*1
The value set in CH Input signal error detection setting value
(Un\G142 to Un\G145) is outside the range of 0 to 250.
The channel where the error has occurred fits in .
Set a value within the range of 0 to 250 in CH
Input signal error detection setting value (Un\G142
to Un\G145).
Error code
(decimal)
Description and cause of error Action
