Appendix 3 I/O Conversion Characteristic of A/D Conversion
Appendix 3 I/O Conversion Characteristic of A/D Conversion
I/O conversion characteristic of A/D conversion means the slope of the line connected between the offset value and
gain value when converting the analog signal (voltage or current input) from outside of programmable controller to
digital value.
(1) Offset value
This is the analog input value (voltage or current) when the digital output value becomes 0.
(2) Gain value
This is the analog input value (voltage or current) when the digital output value becomes 20000.
