CHAPTER 9 DISPLAY UNIT
9
9.3 List of Setting Value Change Screens
9.3 List of Setting Value Change Screens
The following is a list of setting value change screens.
(1) Displayed in English:
Name
Screen
format
Input limits
Setting item Screen display Upper limit Lower limit
A/D conversion enable/disable setting A/D CONVERSION Selection ⎯⎯
Averaging process setting AVE PROCESSING Selection ⎯⎯
Time Average/ Count Average/Moving
Average
TIME/COUNT/MOV Numeric 62500 2
Warning output setting PROCESS ALARM Selection ⎯⎯
Process alarm upper upper limit value PRALARM UPR/UPR Numeric 32767 -32768
Process alarm upper lower limit value PRALARM UPR/LWR Numeric 32767 -32768
Process alarm lower upper limit value PRALARM LWR/UPR Numeric 32767 -32768
Process alarm lower lower limit value PRALARM LWR/LWR Numeric 32767 -32768
Input signal error detection setting INPUT SIG ERR Selection ⎯⎯
Input signal error detection setting
value
INPUT SIG VALUE Numeric 250 0
Scaling function SCALING Selection ⎯⎯
Scaling upper limit value SCALE UP LIMIT Numeric 32000 -32000
Scaling lower limit value SCALE LOW LIMIT Numeric 32000 -32000
Shifting amount to conversion value SHIFT Numeric 32767 -32768
Digital clipping function DIGITALCLIP Selection ⎯⎯
Input signal error detection enhancing
setting value
INPUT SIG ENH Selection ⎯⎯
Conversion speed setting CONVERSION SPD Selection ⎯⎯
