Appendix 5.4 G(P).OGSTOR
(1) Setting data
*1 Specify the device specified to on execution of the G(P).OGLOAD instruction.
Do not change the data which is read out by the G(P).OGLOAD instruction. If the data is changed, the normal operation
may not be ensured.
Setting
data
Internal device
R, ZR
J\
U\G Zn
Constant
K, H, $
Others
Bit Word Bit Word
⎯ ⎯
⎯
Device Description Setting range Data type
Un Start I/O number of module
0 to FE
H
BIN 16 bits
*1
Start number of device where the control data is stored
Within the range of
specified device
Device name
Device which turns ON for one scan at the processing completion of the dedicated
instruction.
In error completion, +1 also turns ON.
Within the range of
specified device
Bit
Command
Command
GP.OGSTOR
G.OGSTOR
SD
SD
GP.OGSTOR
G.OGSTOR
Un
Un
S
D
S
D
D
S
