CHAPTER 5 SYSTEM CONFIGURATION
5
5.1 Overall System Configuration
CHAPTER 5 SYSTEM CONFIGURATION
This chapter describes the overall configuration, number of connectable modules, and compatible software version of
the A/D converter module.
5.1 Overall System Configuration
The following shows a system configuration example for using the A/D converter module.
(1) When connected to a CPU module
(2) When connected to a head module
Power supply module CPU module
Display unit
(optional)
I/O module or
intelligent function
module
END cover
A/D converter module
Power supply module Head module
I/O module or
intelligent function
module END coverA/D converter module
