158
11.2 Checking by Latest Error Code (Un\G19)
The following describes how to check the error codes and alarm codes in Latest error code (Un\G19).
[Online] [Monitor] [Device/Buffer Memory Batch]
11.3 Checking on the Module Error Collection Function
Using the module error collection function stores the errors occurred in the A/D converter module to the CPU module
or the head module. Once being stored, the errors remain even after powering off or resetting the CPU module or the
head module.
(1) How to check the errors by the module error collection function
To check the errors of the A/D converter module collected by the CPU module, open the "Error History" dialog
box.
[Diagnostics] [System Monitor…] click the button
(2) Errors to be collected
The A/D converter module reports the following contents to the CPU module:
• Error code list ( Page 159, Section 11.4)
• Alarm code list (
Page 163, Section 11.5)
To Next Page
