Appendix 1.2 Output signal
(1) Operating condition setting request (Y9)
To validate the following settings, turn Operating condition setting request (Y9) OFF→ ON → OFF.
• A/D conversion enable/disable setting (Un\G0)
•CH Time Average/ Count Average/Moving Average (Un\G1 to Un\G4)
• Averaging process setting (used to replace Q64AD) (Un\G9)
• Averaging process setting (Un\G24)
• Conversion speed setting (Un\G26)
• Input signal error detection extension setting (Un\G27)
• Digital clipping enable/disable setting (Un\G29)
• Input signal error detection setting (Un\G47)
• Warning output setting (Un\G48)
• Scaling enable/disable setting (Un\G53)
•CH Scaling lower limit value (Un\G62, Un\G64, Un\G66, Un\G68)
•CH Scaling upper limit value (Un\G63, Un\G65, Un\G67, Un\G69)
•CH Process alarm lower lower limit value (Un\G86, Un\G90, Un\G94, Un\G98)
•CH Process alarm lower upper limit value (Un\G87, Un\G91, Un\G95, Un\G99)
•CH Process alarm upper lower limit value (Un\G88, Un\G92, Un\G96, Un\G100)
•CH Process alarm upper upper limit value (Un\G89, Un\G93, Un\G97, Un\G101)
•CH Input signal error detection setting value (Un\G142 to Un\G145)
•CH Logging enable/disable setting (Un\G1000 to Un\G1003)
•CH Logging data setting (Un\G1024 to Un\G1027)
•CH Logging cycle setting value (Un\G1032 to Un\G1035)
•CH Logging cycle unit setting (Un\G1040 to Un\G1043)
•CH Logging points after trigger (Un\G1048 to Un\G1051)
•CH Level trigger condition setting (Un\G1056 to Un\G1059)
•CH Trigger data (Un\G1064 to Un\G1067)
•CH Trigger setting value (Un\G1082 to Un\G1085)
•CH Flow amount integration enable/disable setting (Un\G1300 to Un\G1303)
•CH Integration cycle setting (Un\G1308 to Un\G1311)
•CH Flow amount time unit setting (Un\G1316 to Un\G1319)
•CH Unit scaling setting (Un\G1324 to Un\G1327)
For the timing of turning the signal OFF → ON → OFF, refer to the following.
• Operating condition setting completed flag (X9) ( Page 167, Appendix 1.1)
(2) User range write request (YA)
(a) Offset/gain setting mode
Turn User range write request (YA) OFF → ON → OFF to register the adjusted offset/gain setting values in the
A/D converter module.
The data is written to the flash memory at the timing when this signal is turned on from off.
For the timing of turning the signal OFF → ON → OFF, refer to the following.
• Offset/gain setting mode flag (XA) ( Page 167, Appendix 1.1)
(b) Normal mode
Turn User range write request (YA) OFF → ON → OFF to perform the user range restoration.
For the timing of turning the signal OFF → ON → OFF, refer to the following.
• Offset/gain setting mode flag (XA) ( Page 167, Appendix 1.1)
