CHAPTER 3 SPECIFICATIONS
3
3.4 I/O Signal List
3.4 I/O Signal List
The following shows the list of the A/D converter module I/O signals.
For the details of I/O signals, refer to the followings.
• Details of I/O signals ( Page 167, Appendix 1)
The I/O number (X/Y) described above shows the case that the start I/O number of the A/D converter module is set to "0".
Input signal Output signal
Device number Signal name Device number Signal name
X0 Module READY Y0
Use prohibited
X1
Use prohibited
Y1
X2 Y2
X3 Y3
X4 Y4
X5 Y5
X6 Y6
X7 Y7
X8 Warning output signal Y8
X9 Operating condition setting completed flag Y9 Operating condition setting request
XA Offset/gain setting mode flag YA User range write request
XB Channel change completed flag YB Channel change request
XC Input signal error detection signal YC Use prohibited
XD
Maximum value/minimum value reset
completed flag
YD
Maximum value/minimum value reset
request
XE A/D conversion completed flag YE Use prohibited
XF Error flag YF Error clear request
