Appendix 6 Checking Serial Number and Function Version
For details on how to check the serial number and function version, refer to the following.
MELSEC-L CPU Module User's Manual (Hardware Design, Maintenance and Inspection)
MELSEC-L CC-Link IE Field Network Head Module User's Manual
Appendix 7 Addition and Change of Functions
Appendix 7.1 Addition of functions
The following table lists functions added to the A/D converter module and GX Works2, and product information of
compatible A/D converter module and software version of GX Works2.
Appendix 7.2 Change of functions
The following table lists functions changed in A/D converter module and GX Works2, and product information of
compatible A/D converter module and software version of GX Works2.
Added contents
Upper 5 digits of product
information compatible with
the A/D converter module
Compatible version of
GX Works2
Reference
Input range extended mode function
13041 or later 1.62Q or later
Page 67, Section 8.4
Input signal error detection extension
function
Page 74, Section 8.8
Shift function Page 86, Section 8.11
Digital clipping function Page 90, Section 8.12
Difference conversion function Page 94, Section 8.13
Logging function Page 98, Section 8.14
Flow amount integration function Page 110, Section 8.15
Display unit
SHIFT screen Page 136, Section 9.3 (7)
DIGITALCLIP screen Page 136, Section 9.3 (8)
INPUT SIG ENH
screen
Page 136, Section 9.3 (9)
Changed contents
Upper 5 digits of product
information compatible with
the A/D converter module
Compatible version of
GX Works2
Reference
CH Scaling value (digital operation
value) (Un\G54 to Un\G57)
13041 or later 1.62Q or later
Page 221, Appendix 7.2(1)
Maximum value/minimum value hold
function
Page 221, Appendix 7.2(2)
Input signal error detection function Page 221, Appendix 7.2(3)
Warning output function (Process
alarm)
Page 221, Appendix 7.2(4)
Scaling function Page 222, Appendix 7.2(5)
