CHAPTER 7 VARIOUS SETTINGS
7
7.4 Auto Refresh
7.4 Auto Refresh
This function transfers data in the buffer memory to specified devices.
By the auto refresh setting, reading/writing data by programming is unnecessary.
(1) Setting procedure
Open the "Auto_Refresh" dialog box.
1. Start "Auto_Refresh".
Project window [Intelligent Function Module] module name [Auto_Refresh]
2. Click the item to setup, and input the auto refresh target device.
Available devices are X, Y, M, L, B, T, C, ST, D, W, R, and ZR.
When a bit device X, Y, M, L, or B is used, set the number that is divisible by 16 points (example: X10, Y120, M16). Data in
the buffer memory are stored in 16 points of devices from the set device No. (Example: When X10 is set, the data are stored
in X10 to X1F.)
To Next Page
