Logging function
Logging enable/disable setting
0: Enable
1: Disable (default value)
Page 98,
Section 8.14
Logging data setting
0: Digital Output Value
1: Scaling Value (Digital Operation Value) (default value)
Logging cycle setting value
µs: 80 to 32767 (default value: 4)
ms: 1 to 32767 (default value: 4)
s: 1 to 3600 (default value: 4)
Logging cycle unit setting
0: µs
1: ms (default value)
2: s
Logging points after trigger 1 to 10000 (default value: 5000)
Level trigger condition setting
0: Disable (default value)
1: Above
2: Below
3: Pass Through
Trigger data
0 to 4999 (CH1 default value: 54)
(CH2 default value: 55)
(CH3 default value: 56)
(CH4 default value: 57)
Trigger setting value -32768 to 32767 (default value: 0)
Flow amount
integration function
Flow amount integration enable/
disable setting
0: Enabled
1: Disabled (default value)
Page 110,
Section 8.15
Integration cycle setting 1 to 5000ms (default value: 4ms)
Flow amount time unit setting
0: /s (default value)
1: /min
2: /h
Unit scaling setting
0: × 1 (default value)
1: × 10
2: × 100
3: × 1000
4: × 10000
