51
CHAPTER 7 VARIOUS SETTINGS
7
7.3 Parameter Setting
Item Setting value Reference
Basic setting
A/D conversion enable/disable
setting
0: Enable (default value)
1: Disable
Page 63,
Section 8.2
Averaging process setting
0: Sampling Processing (default value)
1: Time Average
2: Count Average
3: Moving Average
Page 63,
Section 8.3
Time Average/ Count Average/
Moving Average
Time
Average
20µs: 2 to 1500ms (default value: 0)
80µs, 1ms: 2 to 5000ms (default value: 0)
Count
Average
4 to 62500 times (default value: 0)
Moving
Average
2 to 1000 times (default value: 0)
Conversion speed setting
0: 20µs
1: 80µs (default value)
2: 1ms
Page 68,
Section 8.5
Warning output
function
Warning output setting
0: Enable
1: Disable (default value)
Page 77,
Section 8.9
Process alarm upper upper limit
value
-32768 to 32767 (default value: 0)
Process alarm upper lower limit value -32768 to 32767 (default value: 0)
Process alarm lower upper limit value -32768 to 32767 (default value: 0)
Process alarm lower lower limit value -32768 to 32767 (default value: 0)
Input signal error
detection
Input signal error detection setting
0: Enable
1: Disable (default value)
Page 69,
Section 8.7
Input signal error detection setting
value
0 to 25.0% (default value: 5.0%)
Input signal error
detection
extension
Input signal error detection extension
setting
0: Disable (default value)
1: Upper and Lower Detection
2: Lower Detection
3: Upper Detection
4: Disconnection Detection
Page 74,
Section 8.8
Scaling function
Scaling enable/disable setting
0: Enable
1: Disable (default value)
Page 80,
Section 8.10Scaling upper limit value -32000 to 32000 (default value: 0)
Scaling lower limit value -32000 to 32000 (default value: 0)
Shift function Shifting amount to conversion value -32768 to 32767 (default value: 0)
Page 86,
Section 8.11
Digital clipping
function
Digital clipping function enable/
disable setting
0: Enable
1: Disable (default value)
Page 90,
Section 8.12
To Next Page
