Appendix 5 Dedicated Instruction Appendix 5.4 G(P).OGSTOR
(2) Control data
Device Item Setting data Setting range Set by
System area ⎯⎯⎯
+1
Completion status
The status on instruction completion is
stored.
0 : normal completion
Other than 0: error completion (error
code)
⎯ System
+2
Pass data classification setting
The value which is set for Pass data
classification setting +2 by
G(P).OGLOAD instruction is stored.
0: voltage
1: current
0000
H
to 000F
H
System
+3
System area ⎯⎯⎯
+4
CH1 Industrial shipment settings offset value (L) ⎯⎯System
+5
CH1 Industrial shipment settings offset value (H) ⎯⎯System
+6
CH1 Industrial shipment settings gain value (L) ⎯⎯System
+7
CH1 Industrial shipment settings gain value (H) ⎯⎯System
+8
CH2 Industrial shipment settings offset value (L) ⎯⎯System
+9
CH2 Industrial shipment settings offset value (H) ⎯⎯System
+10
CH2 Industrial shipment settings gain value (L) ⎯⎯System
+11
CH2 Industrial shipment settings gain value (H) ⎯⎯System
+12
CH3 Industrial shipment settings offset value (L) ⎯⎯System
+13
CH3 Industrial shipment settings offset value (H) ⎯⎯System
+14
CH3 Industrial shipment settings gain value (L) ⎯⎯System
+15
CH3 Industrial shipment settings gain value (H) ⎯⎯System
+16
CH4 Industrial shipment settings offset value (L) ⎯⎯System
+17
CH4 Industrial shipment settings offset value (H) ⎯⎯System
+18
CH4 Industrial shipment settings gain value (L) ⎯⎯System
+19
CH4 Industrial shipment settings gain value (H) ⎯⎯System
+20
CH1 User range settings offset value (L) ⎯⎯System
+21
CH1 User range settings offset value (H) ⎯⎯System
+22
CH1 User range settings gain value (L) ⎯⎯System
+23
CH1 User range settings gain value (H) ⎯⎯System
+24
CH2 User range settings offset value (L) ⎯⎯System
+25
CH2 User range settings offset value (H) ⎯⎯System
+26
CH2 User range settings gain value (L) ⎯⎯System
+27
CH2 User range settings gain value (H) ⎯⎯System
+28
CH3 User range settings offset value (L) ⎯⎯System
S
S
S
S
0
0
CH4 CH3 CH2 CH1
b15 b8 b3 b2 b1 b0b7 b6 b5 b4
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
