202
(56)Latest error code address (Un\G1800)
The latest address of error log is stored.
(57)Error history No. (Un\G1810 to Un\G1969)
Up to 16 errors occurred in the module are recorded.
*1 Those are values when an error occurs at 10:35:40 on Tuesday, March 29th, 2011.
(58)CH Logging data (Un\G5000 to Un\G44999)
This is an area for storing the logged data. Up to 10000 data can be stored per channel. After the 10001st data for
CH Logging data (Un\G5000 to Un\G44999) for each channel, the logging is continued overwriting the data
from the head.
For details on the logging function, refer to the following.
• Logging function ( Page 98, Section 8.14)
● When Operating condition setting request (Y9) is turned OFF → ON → OFF, the logging data in all the channels are
cleared.
● Even if CH Logging hold request (Un\G1008 to Un\G1011) is turned ON (1) → OFF (0) and the logging restarts, the
logged data is not cleared to zero.
Item Storage contents
Storage
example
*1
First two digits of the year/
Last two digits of the year
Stored in BCD code.
2011
H
Month/Day
329
H
Hour/Minute
1035
H
Second
40
H
Day of the week
One of the following values is stored for each day of the week in BCD
code.
2
H
• Sunday: 0 • Monday: 1
• Tuesday: 2 • Wednesday: 3
• Thursday: 4 • Friday: 5
• Saturday: 6
b15
to
b8 b7 b0
to
Error code
First two digits of the year
Last two digits of the year
Month
Day
Hour
Minute
Second
Day of the week
Un\G1810
Un\G1814
Un\G1813
Un\G1812
Un\G1811
Un\G1815
Un\G1819
System area
to
