EQUIPMENT - 5
CAY M A N 2 0 0 7
107
SEAT CONTROLS
The Pilot and Co-pilot seats are adjustable
to provide maximum comfort. Seats must be
locked in the forward facing direction while
traveling.
NOTE:
The seats operate from 12 Volt DC
house power.
Swivel Seats
Swivel Seat Operation:
To swivel, lift up the lever located on the
side control panel.
The passenger seat swivels all the way
around when the slide-out is extended.
When rotating the driver seat, put the
steering wheel in the upright position.
Move the seat forward, then pull the
swivel lever up and rotate to the desired
position.
WARNING:
Seats must be locked in the forward
facing position while the motorhome is
in transit.
NOTE:
After either seat is rotated 180º, it
must be rotated back in the opposite
direction. The 12 Volt wiring in the seat
may disconnect if rotated 360º.
DINETTE BED CONVERSION
To Convert Booth Dinette into a Bed:
Lift seat cushions to an angled vertical
position.
Rotate the lock bar located underneath
the table.
Push the table down into position.
Use both seat cushions and one back
cushion for a mattress. Leave one back
cushion in a vertical position.
WARNING:
DO NOT occupy the booth dinette, if
not equipped with safety belts, or the
dining chairs while the motorhome is
in motion. To avoid personal injury
to occupants in case of a crash or
sudden stop, chairs must be stored in
an enclosed area or secured with tie
down straps while the motorhome is in
motion.
SOFA BED CONVERSION
The sofa will convert easily into a bed. The
sofa comes equipped with safety belts to use
during travel.
Sofa to Sleeper:
Lift up from the center of sofa, just
below the seat cushions, to form a “V”
shape with the seat base and back rest.
Push down on seat base, then pull out
until the seat base and backrest are at.
Fold seat belts out of the way.
020243
060257
020163f
Rotate lock-bar to release table.
LOCK-BAR
