Motorola EP350 Basic Service Manual

5-18 Radio Programming and Tuning: Front Panel Programming
FRONT 1L
(Front Button 1
– Long Press)
- same as above - Program Front Button 1 – Long Press.
FRONT 2S
(Front Button 2
– Short Press)
- same as above - Program Front Button 2 – Short Press.
FRONT 2L
(Front Button 2
– Long Press)
- same as above - Program Front Button 2 – Long Press.
FRONT 3S
(Front Button 3
– Short Press)
- same as above - Program Front Button 3 – Short Press.
FRONT 3L
(Front Button 3
– Long Press)
- same as above - Program Front Button 3 – Long Press.
CHANNEL
ACTIVATE
**
CH-001 ...
CH-099
ENABLE
DISABLE
Enable or disable a channel.
ALIAS
**
CH-001 ...
CH-099
YYYYYYYY Set alias for the channel.
BANDWDTH
**
(Bandwidth)
CH-001 ...
CH-099
12.5 KHZ
25.0 KHZ
Set channel bandwidth at 12.5 kHz or 25 kHz.
The selection will depending on the bandwidth
setting allowed for a particular mode
RX FREQ
**
(Rx Frequency)
CH-001 ...
CH-099
XXX. XXXX Set receiving frequency (in MHz) for the current
channel.
TX FREQ
**
(Tx Frequency)
CH-001 ...
CH-099
XXX. XXXX Set transmitting frequency (in MHz) for the
current channel.
PL DSPLY
**
(PL Display
Type)
FREQ
CODE
PL display type – in frequency or code.
RX PL
**
(Receive TPL/
DPL)
CH-001 ...
CH-099
CSQ CSQ
TPL 067.0 ... 001 ...
TPL 254.1 042
DPL 023 or 043
DPL 754 127
TPL 1 TPL 1
TPL 2 TPL 2
TPL 3 TPL 3
Receive PL
•Frequency: CSQ, TPL 67.0 – TPL 254.1,
DPL 023 – DPL 754, user defined TPL 1, user
defined TPL 2, & user defined TPL 3
•Code: CSQ, 001 – 127, user defined TPL 1,
user defined TPL 2, & user defined TPL 3
TX PL
**
(Transmit TPL/
DPL)
CH-001 ...
CH-099
CSQ CSQ
TPL 067.0 001 ...
TPL 254.1 042
DPL 023 or 043
DPL 754 127
TPL 1 TPL 1
TPL 2 TPL 2
TPL 3 TPL 3
Transmit PL
•Frequency: CSQ, TPL 67.0 – TPL 254.1,
DPL 023 – DPL 754, user defined TPL 1, user
defined TPL 2, & user defined TPL 3
•Code: CSQ, 001 – 127, user defined TPL 1,
user defined TPL 2, & user defined TPL 3
TPL 1
**
067.0
067.1 ...
254.9
255.0
Non-standard private line (TPL) frequency.
67.0 Hz – 255.0 Hz with 0.1 Hz step.
Table 5-9. Front Panel Programming Mode Parameters (Continued)
Main Menu
1st Level
Sub-Menu
2nd Level
Sub-Menu
Setting Remarks

Motorola EP350 Specifications

General

Channel Capacity	16 channels
IP Rating	IP54
Drop Resistance	1.2 meters
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Battery Life	Up to 11 hours
Power Supply	7.5 V (Nominal)
Waterproof	Splashproof
Dimensions	127.6 x 62 x 42 mm (with standard battery)
