GENERAL
Tag Type: ISO/IEC 15693
NOTE: Contains radio Bluetooth
MAC address to assist fast pairing
with smart device and radio serial
number.
RFID
Tag Type: 866-868 MHz or 902-928 MHz
1.1.2
Receiver Specifications
Table 4: Receiver Specifications
RECEIVER
Receiver Type: Class A and B
Frequency Range: 350.0–470.0 MHz
Channel Spacing: 25 kHz
Sensitivity (3.5%) BER:
MXP600
MXP600 FuG
-116 dBm (guaranteed)
-118 dBm (typical)
Intermodulation: (3.5%) BER
Interfering Signal Level -47 dBm
Selectivity Blocking:
(50–100 kHz)
(3.5%) BER
Interfering Signal Level -40 dBm
Spurious Rejection: (3.5%) BER
Interfering Signal Level -45 dBm
Frequency Stability:
Locked to Base ±100 Hz
Unlocked to Base ±1000 Hz
Audio Rated 2 W
Distortion at Rated Audio: 1% Max.
1.1.3
Transmitter Specifications
Table 5: Transmitter Specifications
TRANSMITTER
Modulation Type: π/4DQPSK
RF Power: Class 4
MN006362A01-AL
Chapter 1 : Model Information
