Chapter 7
Radio Disassembly and Reassembly
Mechanical checks and self-tests should be performed on the unit at the basic level of service.
NOTE: Read each procedure thoroughly before performing the actual task.
7.1
Torque Specification Chart
Use the recommended torque value in this chart when fastening different parts of the radio.
Table 26: Torque Specification Chart
Description Part/Kit Torque
Main Board Screw to capsule insert. 0304726J05 2.2±0.1 lb-in
Chassis Screw to front housing insert. FN000454A01 3.6±0.1 lb-in
Keypad Screw to front housing insert. FN000509A01 1.1±0.1 lb-in
Encoder Nut FN000503A01 5.0±0.1 lb-in
Antenna Nut FN000552A01 12±0.1 lb-in
Keypad Flex Retainer Screw 0378212A01 1±0.1 lb-in
7.2
Installing or Uninstalling the MicroSD Card
NOTE: Applicable only for SD Card model.
The microSD card slot has a delicate construction. You must avoid installing or uninstalling
the microSD card unnecessarily as this action can damage the mechanism of the reader. For
copying files from your radio, you can use the USB Mass Storage Mode.
Installing the MicroSD Card
Prerequisites:
Your radio is equipped with a microSD card slot.
Procedure:
1 Remove the battery.
2 Flip open the plastic door from the finger scoop area.
NOTE: Avoid pressing on the plastic door.
