Motorola MXP600 - Transmitter Tests

Test Name Test Setup Radio Setup Test Condi-
tions
Limits
34.5 dBm (Class
3)
Access Parame-
ter
N/A –53 dBm N/A
Mobile Power 30.0 dBm (Class
4)
32.5 dBm (Class
3L)
N/A N/A
Burst Type N/A Normal N/A
Transmitter
Burst Power
RF Gen Level
Burst Power
N/A –90 dBm 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
33.0–37.0 dBm
(Class 3)
Timing Error N/A N/A ±0.25 Symbols
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
Call Processing
Talk Back
1 kHz Test Sig-
nal Group Mode
N/A –50 dBm N/A
Call Processing
Call to Mobile
Private 4-digit random
number and
Send
N/A 28.0–32.0 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
33.0–37.0 dBm
(Class 3)
RF Gen Level
Burst Power
N/A –90 dBm 28.0–32.0 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
33.0–37.0 dBm
(Class 3)
Timing Error N/A N/A ±0.25 Symbols
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
4.2.1
Transmitter Tests
1 Power Burst (Control Range)
MN006362A01-AL
Chapter 4 : Test Setup and Testing
36
