Motorola MXP600 - Testing Charger Recognition

Bluetooth Test
55 The display shows:
Bluetooth
Test
56 Do the following:
Action Result
Press any key. The display shows:
BT test - pairing
WAIT !!!
Wait for result. The display shows pairing test result.
Press any key to continue. The display shows pairing connection test result.
Press any key to continue. The display shows:
BT microphone
test - start
Speak into the internal mi-
crophone.
You hear yourself in the paired Bluetooth audio speaker.
Press any key to continue. The display shows:
BT speaker
test - start
Speak into the paired Blue-
tooth microphone.
You hear yourself in the internal speaker.
57 Press the corresponding key to proceed to the next test.
The display shows:
The test is
completed.
Press any key
to turn the
radio OFF.
Test is completed. Press any key to turn the radio OFF.
Postrequisites: For WiFi, use the radio feature user guide for WiFi setup and WiFi communication
test.
NOTE: WiFi is not supported for customer.
4.12.2
Testing Charger Recognition
Procedure:
1 Turn the radio ON.
2 Connect the Rapid Travel Charger accessory connector to the handset. Check the following:
• LCD display shows charger connected.
• A beep is heard.
• Keypad back-light is turned ON.
• Charging icon is shown.
MN006362A01-AL
Chapter 4 : Test Setup and Testing
54
