Motorola MXP600 - Page 53

Rotary
Test
50 Do the following:
Action Result
Press any key. The display shows:
>
> >
> >
> >
> >
> >
> >
> >
>
Turn the rotary knob clock-
wise. Each click removes
the respective clockwise ar-
row until display is empty.
The display shows:
<
< <
< <
< <
< <
< <
< <
< <
<
Turn the rotary knob coun-
ter-clockwise. Each click re-
moves the respective clock-
wise arrow until display is
empty.
The display shows:
Press the Rotary
51 Press the corresponding key to proceed to the next test.
Man Down (henceforth known as Fall Alert) Test
52 The display shows:
Mandown
Test
53 Do the following:
Action Result
Press any key. The display shows:
45 Degree Angle
Angle Detection
Mandown Test
Place the radio horizontally
on a flat surface.
A beep sounds after 10 seconds. Man Down (Fall Alert)
angle detection feature is functional.
Press any key to continue. The display shows:
No-Movement
Mandown Test
Place the radio in a stable
position.
A beep sounds after 10 seconds. Man Down (Fall Alert)
angle detection feature is functional.
54 Press the corresponding key to proceed to the next test.
