Action Result
Press Any key
To Continue
33 Press the corresponding key to proceed to the next test.
Accessory Connect Test
34 The display shows:
Accessory
Connect Test
35 Do the following:
Action Result
Press any key. The display shows:
Connect
GCAI/BC:
1. Core Accy
2. IMPRES Accy
to the radio
and press any key
Attach Core or IMPRES ac-
cessory to the GCAI/Bottom
connector.
The display shows:
WAIT!!!
GCAI/Bottom
Connector Recognized
Accessory xxxx
connected
Press any key
to continue
36 Press the corresponding key to proceed to the next test.
Tones Test
37 The display shows:
Tones
Test
38 Do the following:
Action Result
Press any key. The display shows:
Internal Speaker Tone Test
The speaker plays a continuous tone.
Press any key. The display shows:
Internal Earpiece Tone Test
The internal earpiece plays a continuous tone.
Press any key. The display shows:
Connect RSM
accessory
to the radio
(RSM connected)
MN006362A01-AL
Chapter 4 : Test Setup and Testing
50
