No. Part/Kit Number Description Remark
3 DM000154A01 Display and flex assembly Serviceable.
4 HW002450A01 Display pad ( For X-Y Toler-
ance purpose)
Serviceable.
5 - Low audio capsule assembly Not serviceable. Included in
Front housing assembly kit.
6 HW001327A01 Speaker Poron Serviceable.
7 - Speaker electromagnetic Not serviceable. Included in
Front housing assembly kit.
8 - Encoder seal Not serviceable. Included in
Front housing assembly kit.
9 - Top Control and Encoder Flex Not serviceable. Included in
Front housing assembly kit.
10 HW002088A01 Conductive Pad Serviceable.
11 PA002767A01 Keypad Flex Assembly Serviceable (For
PMHN4421_).
PA002767A02 Keypad Flex Assembly Serviceable (For PMHN4457_,
PMHN4462_).
12 LB001682A01 Keypad Flex Adhesive Serviceable.
NOTE: Replace
LB001682A01
when reus-
ing PA002767A01/
PA002767A02
13 0402838X02 Encoder washer Serviceable.
14 FN000503A01 Encoder nut Serviceable.
15 HW001341A01 Knob Serviceable.
16 HW001187A02 SMA washer Serviceable.
17 FN000552A01 SMA Nut Serviceable.
18 - SMA o-ring Not serviceable. Included in
Front housing assembly kit.
19 - SMA Connector Not serviceable. Included in
Front housing assembly kit.
20 - Mini GCAI PCB Not serviceable. Included in
Front housing assembly kit.
21 0104082J25 Vibrator Assembly Serviceable.
MN006362A01-AL
Chapter 6 : Replacement Parts
64
