Description
Chillgard 5000
US
Fig. 5 Bottom of device
Fig. 6 Internal touchpoints
1 Sample line identification labels
2 Internal alarm sounder
3 Calibration port
4 IP rated vent
5 Exhaust port (do not block)
1 Fuses
2 AC wiring cover
3 Internal filters
4 ESD tie-off location
1
1
2
3
4
5
1
2
3
3
4
3
