Appendix C: Default Settings
Chillgard 5000
US
16 Appendix C: Default Settings
16.1 Alarm Setpoints
The default settings for the alarm setpoints are the following:
• 5, 20, and 50 percent of full-scale range, except for R123, which are 1, 2, and 5 percent of full-
scale range
•Non-latching
• Horn and strobe (if applicable) enabled
16.2 Relays
The default setting for the internal fault relay is the energized state. All other relays (alarm, warning,
caution, and horn) are set to de-energized.
16.3 Output
The default setting for digital output is None. The factory default settings for analog output are 3.5 mA
for Warm-up and 2.0 mA for Fault.
