77
Appendix B: Installation of Optional Equipment
Chillgard 5000
US
15.3 External Alarm Activation Station
(1) Disconnect electrical power to the device.
(2) If applicable, remove the locking mechanism.
(3) Release the two latches on the left side of the device.
(4) Open the enclosure.
(5) Attach the ESD wrist strap to the ESD connection point inside the enclosure.
(6) Follow the wiring instructions supplied with the alarm activation station.
(7) Insert the wires for the alarm activation station into the Phoenix connector marked "PULL" on the
circuit board. Make sure the wires are inserted correctly.
(8) Use a small flathead screwdriver to tighten the screws on the Phoenix connector and secure the
wires.
(9) Disconnect the ESD wrist strap from the ESD connection point inside the enclosure.
(10) Close the enclosure.
(11) Latch the two latches.
(12) If applicable, attach the locking mechanism.
(13) Supply electrical power to the device.
15.4 External Alarm Silencing Station
(1) Disconnect electrical power to the device.
(2) If applicable, remove the locking mechanism.
(3) Release the two latches on the left side of the device.
(4) Open the enclosure.
(5) Attach the ESD wrist strap to the ESD connection point inside the enclosure.
(6) Follow the wiring instructions supplied with the alarm silencing station.
(7) Insert the wires for the alarm silencing station to the Phoenix connector marked "ACK" on the
circuit board. Make sure each wire is inserted into the correct connector terminal.
(8) Use a small flathead screwdriver to tighten the screws on the Phoenix connector and secure the
wires.
(9) Disconnect the ESD wrist strap from the ESD connection point inside the enclosure.
(10) Close the enclosure.
(11) Latch the two latches.
(12) If applicable, attach the locking mechanism.
(13) Supply electrical power to the device.
