Appendix E: BACnet Objects
Chillgard 5000
US
18 Appendix E: BACnet Objects
18.1 Chillgard 5000 - BACnet
Section Object Name Channel # Object Type Inst # Property Notes
General
Product ID
General
Analog Input 1 Read "CG"
Firmware Version Analog Input 2 Read
Build(MSB:2b)/Major(1b)/
Minor(1b)
Reserved 4 Analog Input 4 Read 0
Reserved 5 Analog Input 5 Read 0
Reserved 6 Analog Input 6 Read 0
Unit Status Analog Input 7 Read
Refer to Section 18.3, "Unit
Status Flags"
ACK button Analog Input 8 Write ACK by writing 1 to it
RESET button Analog Input 9 Write
Refer to Section 18.2,
"RESET Button Actions"
Channels
1Gas Number
Channel 1
Analog Input 10 Read
Refer to Section 18.5, "Gas
Types"
1 Gas Conc. Analog Input 11 Read ppm
1 Status Analog Input 12 Read
Refer to Section 18.4,
"Channel Status Flags"
1 Reserved Analog Input 13 Read 0
2Gas Number
Channel 2
Analog Input 14 Read
Refer to Section 18.5, "Gas
Types"
2 Gas Conc. Analog Input 15 Read ppm
2 Status Analog Input 16 Read
Refer to Section 18.4,
"Channel Status Flags"
2 Reserved Analog Input 17 Read 0
3Gas Number
Channel 3
Analog Input 18 Read
Refer to Section 18.5, "Gas
Types"
3 Gas Conc. Analog Input 19 Read ppm
3 Status Analog Input 20 Read
Refer to Section 18.4,
"Channel Status Flags"
3 Reserved Analog Input 21 Read 0
4Gas Number
Channel 4
Analog Input 22 Read
Refer to Section 18.5, "Gas
Types"
4 Gas Conc. Analog Input 23 Read ppm
4 Status Analog Input 24 Read
Refer to Section 18.4,
"Channel Status Flags"
4 Reserved Analog Input 25 Read 0
