Description
Chillgard 5000
US
Analog Output Settings
0–10 Vdc
The voltage output can be used to identify any active gas sample line.
While the device is in calibration mode, the output is 10 Vdc.
Warm-up Default = 3.5 mA
User adjustable between 0 and 3.75 mA
Calibration (nonconfigurable) 3.0 mA
Fault Default = 2.0 mA
User adjustable between 0.5 and 3.75 mA
Device over range (nonconfigurable) 21 mA
Sample Line
Vdc
4 or 8 pt system
Vdc
16 pt system
111.0
221.5
332.0
442.5
553.0
663.5
774.0
884.5
9- 5.0
10 - 5.5
11 - 6.0
12 - 6.5
13 - 7.0
14 - 7.5
15 - 8.0
16 - 8.5
