Description
Technical specifications
42 10.06.2014
Dimensions
Height (a) with open chamber lid 1390 mm
Height (a) with closed chamber
lid
1020 mm
Operating height approx. 900 mm
Width (b) without gas mixer 570 mm
Width (b) with gas mixer 720 mm
Depth (c) 695 mm
Effective chamber size (W/H/D) 440 mm/160 mm (optional 230
mm)/470 mm
Sealing length 440 mm
Weight approx. 160 kg
Fig. 40: Dimensions
Installation conditions and ambient conditions
Ambient temperature +2 °C to +40 °C
Storage temperature -25 °C to +80 °C
Relative air humidity during op-
eration or storage of the ma-
chine, max.
90 % non-condensing
Inclination of the machine during
transport, max.
15 °
