32 Loading media
2. Adjusting the table’s height
[1]
Open the PG handwheel cover, by pressing on it.
[2]
Turn the PG handwheel to lower the table.
• Lower it until the surface height of the media gets lower than the height of
side plates on both sides.
Note
Turn the PG handle clockwise.
[3]
Place the media height guide on the side plates over the table.
• Make sure that the media height guide is placed on the side plates on both
sides.
[4]
Turn the PG handwheel to raise the table to the position where the
media touches the media height guide.
Note
Turn the PG handle anti-clockwise.
To Next Page
