MUTOH XPJ-461UF - Page 53

Checking the printing area 53
• The LED pointer moves to the top right corner of the print range
(position4).
• The LED pointer remains on while moving.
• After moving, the LED pointer flashes every second, for a total of 3
times.
Note
When the print data’s length (PF length) is too big for the media, the LED
pointer flashes twice a second, for a total of 6 times after moving.
[5]
Check that the LED pointer’s position is not misaligned with the media
position, and then tap [Enter].
Note
• The LED pointer remains on until [Enter] is tapped.
• To cancel the job, use or to choose "No", then tap [Enter].
• The LED pointer moves to the bottom right corner of the print range
(position1).
• The LED pointer remains on while moving.
• After moving, the LED pointer flashes every second, for a total of 1
time.
• The carriage returns to the original position (capping station).
• Checking the print range is complete.
[6]
Use or to select “Yes”.
•Tap [Enter].
Note
To cancel the job, use or to choose "No", then tap [Enter].
ShowingPrintArea
Position4OK？
 Yes
ShowingPrintArea
PleaseWait
StartPrinting?
No
