122 Ramp
MANUAL RAMP
Check to make sure path for the ramp deployment is clear of
people and objects.
Your vehicle may be equipped with a manual ramp. This ramp
extends out to 63.75 in (1619 mm) 1:4.1 ratio slope and can be
pulled out and stowed by one person. The load limit for the
manual ramp is 660 lbs (299.6 kg).
DO NOT exceed the load limit on the ramp.
REASON: Exceeding the load limit could cause damage
to the ramp, personal injury or death.
NOTE: For information on the proper boarding and
securing of passengers in wheelchairs, see the Wheelchair
Restraints on page 84.
Ramp Deployment
DO NOT deploy the ramp in any conditions or areas where
boarding or exiting via the ramp cannot be safely performed.
REASON: Boarding or exiting in areas where the ramp
is not stable could cause serious personal injury or death.
To pull out the manual ramp:
1. Hold down the storage latch on the left side of the ramp.
